110-320 Rod Antenna

Tri-Band, Dual Input, 121.5, 243 & 406 MHz



Find a dealer

SKU: 110-320 Category: Tags: , , , , , ,

PRODUCT DESCRIPTION

Tough, glass-reinforced polyester housing covers our innovative Tri-Band technology, bringing 121.5, 243, and 406 MHz into a compact package. This highly efficient antenna offers 10 dB of isolation between ports. The CI 317 provides a dual connector configuration for those installations that require this set-up. Designed to meet the Eurocae ED 62 flame test.

Two Models Available:

  • 110-320 (white)
  • 110-320-04 (black)

Additional information

Weight 0.00 lbs

Frequency

121.5, 243 & 406 MHz



VSWR

2.0:1 – 121.5/243 MHz, 1.5:1 – 406 MHz



Polarization

Vertical



Radiation Pattern

Omni-directional



Impedence RF

50 OHMS (nominal)



Power RF

25 Watts



Weight

0.45 lbs.



Height

15.50”



Material

Molded radome/fiberglass whip



Finish

Polyurethane enamel



Connector

BNC (female) for 121.5/243 MHz, TNC (female) for 406 MHz



Temperature

-55˚ C to + 85˚ C



Altitude

55,000’



Color

110-320 (white), 110-320-04 (black)



Gasket

B31725(optional to order separately)

WARRANTY LENGTH: 30 MONTHS FROM DATE OF INSTALLATION OF THE GOODS ON BUYERS SOLUTION, 24 MONTHS FROM THE DATE OF DISPATCH OF GOODS BY THE SUPPLIER



Warranty coverage is effectively extended from previous warranties offered on Artex products. To qualify for warranty coverage, a customer must do one of two things.



1) Provide the original packing list from Artex with a shipping date on it. The warranty period expires 24 months from the date shipped on the packing list.

2) Provide proof of installation date (Logbook entry, signed copy of the FAA form 337 the ELT was installed under, or other documentation stating such).



If the customer is unable to provide either methods of documentation, the warranty will apply for 24 months from date of manufacture listed on the ELT product label, with a 6 month installation grace period – effectively 30 months.



For any inquiries regarding warranties, feel free to contact Artex products technical support at: artexsupport@acrartex.com or by phone at USA +1 (954)-981-3333.
